SLD
© Maximilian Gödecke
© Maximilian GödeckeChokesSLD
Protective conductor chokes
Chokes ready for connection to reduce parasitic current and voltage peaks on the protective conductor.
- Inductance tolerance
- −30 % / +50 %
- Test voltage Uₚ
- 3.000 VDC, 2 s
- IEC 60068-1 climatic category
- 25/100/21
SLD / Technical data
Details for your design.
| Inductivity Tolerance | – 30 % to + 50 % |
|---|---|
| Test Voltage U p | 3.000 VDC, 2 s |
| IEC 60068-1 Climate Category | 25/100/21 |
Scroll horizontally to see all columns
| Enquiry | |||||
|---|---|---|---|---|---|
| SLD-4-16-1-005-_-__ | 480 V AC | 16 A | 1 | 0,5 mH | Enquire |
| SLD-4-16-1-010-_-__ | 480 V AC | 16 A | 1 | 1,0 mH | Enquire |
| SLD-4-16-1-012-_-__ | 480 V AC | 16 A | 1 | 1,2 mH | Enquire |
| SLD-4-16-1-015-_-__ | 480 V AC | 16 A | 1 | 1,5 mH | Enquire |
| SLD-4-16-1-020-_-__ | 480 V AC | 16 A | 1 | 2,0 mH | Enquire |
| SLD-4-16-1-025-_-__ | 480 V AC | 16 A | 1 | 2,5 mH | Enquire |
| SLD-4-16-1-030-_-__ | 480 V AC | 16 A | 1 | 3,0 mH | Enquire |
| SLD-4-16-1-035-_-__ | 480 V AC | 16 A | 1 | 3,5 mH | Enquire |
| SLD-4-16-1-040-_-__ | 480 V AC | 16 A | 1 | 4,0 mH | Enquire |
| SLD-4-25-1-005-_-__ | 480 V AC | 25 A | 1 | 0,5 mH | Enquire |
| SLD-4-25-1-010-_-__ | 480 V AC | 25 A | 1 | 1,0 mH | Enquire |
| SLD-4-25-1-012-_-__ | 480 V AC | 25 A | 1 | 1,2 mH | Enquire |
| SLD-4-25-1-015-_-__ | 480 V AC | 25 A | 1 | 1,5 mH | Enquire |
| SLD-4-25-1-020-_-__ | 480 V AC | 25 A | 1 | 2,0 mH | Enquire |
| SLD-4-25-1-025-_-__ | 480 V AC | 25 A | 1 | 2,5 mH | Enquire |
| SLD-4-25-1-030-_-__ | 480 V AC | 25 A | 1 | 3,0 mH | Enquire |
| SLD-4-25-1-035-_-__ | 480 V AC | 25 A | 1 | 3,5 mH | Enquire |
| SLD-4-25-1-040-_-__ | 480 V AC | 25 A | 1 | 4,0 mH | Enquire |
| SLD-4-36-1-005-_-__ | 480 V AC | 36 A | 1 | 0,5 mH | Enquire |
| SLD-4-36-1-010-_-__ | 480 V AC | 36 A | 1 | 1,0 mH | Enquire |
| SLD4-36-1-012-_-__ | 480 V AC | 36 A | 1 | 1,2 mH | Enquire |
| SLD-4-36-1-015-_-__ | 480 V AC | 36 A | 1 | 1,5 mH | Enquire |
| SLD-4-36-1-020-_-__ | 480 V AC | 36 A | 1 | 2,0 mH | Enquire |
| SLD-4-36-1-025-_-__ | 480 V AC | 36 A | 1 | 2,5 mH | Enquire |
| SLD-4-36-1-030-_-__ | 480 V AC | 36 A | 1 | 3,0 mH | Enquire |
| SLD-4-36-1-035-_-__ | 480 V AC | 36 A | 1 | 3,5 mH | Enquire |
| SLD-4-36-1-040-_-__ | 480 V AC | 36 A | 1 | 4,0 mH | Enquire |
27 entries
Designs and availability on request.
Design & ordering
The product in detail.
Ground wire chokes are an effective means to suppress parasitical current and voltage peaks on the ground wire. If necessary, our fully wired ground wire chokes SLD can be integrated into electrical devices economically and fast.
Description
- RoHS- and REACH-compliant
- single-phase design
- low ohmic resistance despite compact design
- closed construction in plastic or metal housing with screw-on bolt
- customized connection with pins, plug contacts, wires, screwed contact terminals or wires with plug contacts
Our product key for your order
Please refer to the table below for detailed technical specifications of our ground wire chokes SLD. We are prepared to customize these standard products according to your demands individually. Other inductances are available on request.
Understanding the product key
How to read the designation.
The following example explains the structure of the product key. Available designs and combinations are provided on request.
SLD-4-25-1-012-W25-ZM- 01
SLDProduct type
Protective conductor choke
- 02
4Rated voltage
480 V AC
Codes shown in the diagram (4)
- 2
- 275 V AC
- 4
- 480 V AC
- 6
- 660 V AC
- 9
- 1000 V AC
- 03
25Rated current
25 A
Codes shown in the diagram (4)
- 16
- 16 A
- 25
- 25 A
- 36
- 36 A
- 50
- 50 A
- 04
1Number of phases
Single-phase, e.g. PE, as labelled in the diagram
Codes shown in the diagram (1)
- 1
- Single-phase, e.g. PE
- 05
012Inductance
1.2 mH
Codes shown in the diagram (9)
- 005
- 0.5 mH
- 010
- 1.0 mH
- 012
- 1.2 mH
- 015
- 1.5 mH
- 020
- 2.0 mH
- 025
- 2.5 mH
- 030
- 3.0 mH
- 035
- 3.5 mH
- 040
- 4.0 mH
- 06
W25Electrical connections
Stranded wire 2.5 mm²
Codes shown in the diagram (5)
- G68
- Stranded wire 1.5 mm² with plug contacts 6.8 × 0.8 mm
- W15
- Stranded wire 1.5 mm²
- W25
- Stranded wire 2.5 mm²
- W40
- Stranded wire 4.0 mm²
- W60
- Stranded wire 5.0 mm²
- 07
ZMHousing
Cylindrical metal housing
Codes shown in the diagram (4)
- ZM
- Cylindrical metal housing
- PK
- Prismatic plastic housing
- OG
- Without housing
- ZK
- Cylindrical plastic housing
